Albin Submersible Heavy Duty Bilge Pump – 1750 GPH 12V

Easily installed and robustly engineered for maximum lifetime. Submersible for harsh saltwater and freshwater use; featuring heavy duty motor with stainless steel shaft; mechanical shaft seal; durable high impact thermoplastic housing and universal base screen. Designed to be interchangeable with same type bilge pumps on the market.

Features

  • Weight: 0,7 kg/1 Lb
  • Submersible for harsh saltwater and freshwater use
  • Liquid cooled for extended motor life
  • Heavy duty, AISI 316 steel shaft, double ball bearing motor
  • Quality engineered mechanical seal
  • Manual operation; automatic operation with optional float switch (APM 01-66-025) or digital bilge switch (APM 01-66-037)
  • Removable check valve included
  • Complies with ISO 8848, EN 55014 Marine
  • Universal base plate with strainer and pin (for “T-slot”) to attach a level switch for automatic operation
  • Designed to be interchangeable with similar type bilge pumps
  • Recommended for boat lengths > 10 m (33 feet)

For product information, availability and pricing, please call +852 2827 5876 or use our contact page.

Description

Albin Submersible Heavy Duty Bilge Pump – 1750 GPH 12V

Albin Submersible Heavy Duty Bilge Pump - 1750GPH for 12V CircuitsSubmersible heavy duty bilge pump 12V with pump capacity 110 L/min (1750 GPH) at 1m head. Stainless steel shaft, double ball bearings, mechanical seal, tough thermoplastic ABS housing and a robust long-life motor design.

Universal base plate with strainer and pin (for “T-slot”) to attach a level switch for automatic operation. Including check valve, 28mm (1.1/8″) to 32mm (1.1/4″) ports. Amperage 7.7A, fuse size 10A.

For pleasure or commercial boats above 10m (30Ft) length. Interchangeable with Rule 1500, Johnson Pump 16004-00 /32-1600-01.

Developed for safe performance in all weather conditions and bilge environments. Easy to install and also robustly engineered to maximize lifetime. For harsh saltwater and freshwater use, heavy duty motors with stainless steel shaft as well as durable high impact thermoplastic housing. Designed to be interchangeable, classified as safety products with 2 years limited warranty.

Features

  • Weight: 0,7 kg/1 Lb
  • Submersible for harsh saltwater and freshwater use
  • Liquid cooled for extended motor life
  • Heavy duty, AISI 316 steel shaft, double ball bearing motor
  • Quality engineered mechanical seal
  • Manual operation; automatic operation with optional float switch (APM 01-66-025) or digital bilge switch (APM 01-66-037)
  • Removable check valve included
  • Complies with ISO 8848, EN 55014 Marine
  • Universal base plate with strainer and pin (for “T-slot”) to attach a level switch for automatic operation
  • Designed to be interchangeable with similar type bilge pumps
  • Recommended for boat lengths > 10 m (33 feet)
Part No. Capacity
Capacity 3ft (1m) head
Ports Voltage Fuse Dimensions WxDxH Replaces
01-03-011 34.5 L / min (9.1 GPM) 1750 GPH (110 L/min) 25 mm (1″) and
32 mm (1 1/4″)
12V 6A 170 x 158 x ⌀130 mm
(6.7 x 6.2 x ⌀ 5.1 inches)
Rule 1500
Johnson Pump 16004-00
/32-1600-01
