SILVA 100B/H Compass – Bulkhead Mount with Illumination
The Silva 100B/H compass is designed for sailboats and yachtsmen that demand absolute accuracy, a steady card in all conditions and furthermore, high heeling angles. You mount the compass in the bulkhead.
It is equipped with a heeling angel scale, illumination and also the possibility to compensate for magnetic field disturbance. The capsule protrudes only 18mm into the cockpit, therefore enabling flexible installation.
SILVA 100B/H Compass Features
- Read from front and above with the double scales
- Built in compensator
- Heeling scale
- Built in Illumination enables night navigation
- Curved lubber lines allow accurate reading from different angles
- Compact size
- Accuracy of ± 0,5° (8.9 mils)
- Calibrated for Magnetic North (good for Hong Kong, Macau and also other parts of Asia)
- Weight 910g
|Accuracy||± 0,5° (8.9 mils)|
|Apparent card diameter||100mm|
|Heeling angle||Roll: 45° Pitch: 30°|
|Heeling angle scale||Yes|
|Lubber lines||Centre and 2x side view at 45°|
|Temperature operating range||-10°C to +70°C|
|Type of compass||Steering compass|
Bulkhead Mount Compasses
SILVA specifically designed bulkhead mount compasses for sailboats and yachtsmen who demand absolute accuracy and a steady card in all conditions as well as high heeling angles.
The gimballed lubber lines stay vertical even if the boat is heeling (max 45°). The extra two lubber lines at 45° permit reading from the rail as well as an off steering position.
